Applicable scope

Nylon PLA mesh non - woven PET can be ultrasonic sealing materials

Performance characteristics

1.With ultrasonic bonding,the size of 20 * 20mm label paper fixed at 120,140 160 180 four wide can be ultrasonic sealing material

2.Can accurately control the adhesion fastness and the effect,the trigger type ultrasonic stability is high,the failure rate is extremely low

3.Multi-point light control to ensure that the mesh without spaces,such as paste paste failed

4.Using Siemens PLC control,with Siemens touch screen operation,the whole parameter touch screen settings (line length,bag length,label length)

5.High-precision feeder to ensure a high degree of tight membrane balance

6.Full high-precision servo control,accurate to 0.1mm

7.long and short line switch

Main technical parameter

model	SF-60TAG
Production speed	50-60標/分
Mesh type	尼龍、PET、PLA網布、無紡布
Mesh width	120、140、160、180（mm）
Label size	20*20（mm）
Tag line length	125mm、150mm、170mm
Tag roll requirements	寬幅20mm，膜需符合要求
Backing roll requirements	寬幅30mm，襯紙需符合要求
The core of the roll core	Φ76mm
The outer diameter ofthecloth	≤Φ400mm
Adhesive form	超聲波
Ultrasonic quantity	4套
Finished product pass rate	≥99.8%
Air pressure	≥0.6Mpa(由定做方保證供氣)
The motor power of the machine	AC220V/50HZ
Operator	1人
Equipment shape	主機： L 1200xW 1100xH 1800mm 收料機： L 700xW 600xH 1300mm
Equipment weight	約500kg
